A highly productive 44-inch printer that combines performance, quality and value to save you time and money
The SureColor SC-T7200 maximises performance in busy graphics, CAD and GIS production environments. Powerful image processing and a fast print speed meet the market's need for maximum productivity and flexibility. Epson's PrecisionCore TFP printheads do not need replacing and, together with UltraChrome XD ink, deliver the highest level of performance, value and versatile media support
Ideal for graphics, CAD and GIS
The SureColor SC-T7200 is one of the SureColor SC-T series of high-speed, four-colour large-format printers, designed to produce a wide range of high-quality graphics, CAD and GIS applications in design, commercial print, copy shop, architecture, building, engineering, retail and education environments.
Highly productive
To maximise productivity, the SureColor SC-T7200 features 1GB of RAM for ultra-fast image processing, and an optional 320GB HDD for job caching and recall. Optional PostScript support with dual 1.6GHz CPUs enables printing of large data-rich files quickly and directly from leading design and CAD programs. And the SureColor SC-T7200 is fast — outputting an A1 print takes just 28 seconds.
High quality output
The combination of Epson’s PrecisionCore TFP printheads and UltraChrome XD pigment ink delivers industry-leading output quality and precise, repeatable performance. UltraChrome XD pigment ink is smudge and water resistant and delivers deep blacks and crisp, dense lines — ideal for technical graphics — and the vibrant colours necessary for high-quality prints and posters, on coated and non-coated media — including board up to 1.5mm thick.
Compact, quiet and easy to use
With its sleek styling, compact footprint, low noise levels and front operation, the SureColor SC-T7200 is designed to fit easily into an office environment.
Key Features
- Fast processing High-speed printing of Graphics, CAD and GIS applications
- Large-capacity ink cartridges A choice of 110, 350 and 700 ml sizes mean a low TCO
- PrecisionCore TFP printhead Permanent printheads for duration of printer lifetime
- UltraChrome XD inks Produce quality, vibrant, smudge- and water-resistant images
- PostScript support with 2 x1.6GHz CPUs Print multiple formats, including data-rich files, quickly and directly.
Technology
Printing Method
PrecisionCore™ TFP print head
Ink Technology
Ultrachrome® XD
Print
Number of colours
5 colour
Colours
Photo Black [Pigment], Matte Black [Pigment], Cyan [Pigment], Yellow [Pigment], Magenta [Pigment]
Colours Capacity
Black [110ml, 350ml, 700ml], Photo Black [110ml, 350ml, 700ml], Cyan [110ml, 350ml, 700ml], Yellow [110ml, 350ml, 700ml], Magenta [110ml, 350ml, 700ml]
Minimum Droplet Size
3,5 pl, With Variable-Sized Droplet Technology
Minimum line width
0,02 mm
Nozzle Configuration
720 Nozzles Black, 720 Nozzles per Color
Printing Resolution
2.880 x 1.440 DPI
Paper / Media Handling
Paper Formats
A0, A1, A2 (42.0x59.4cm), A3+, A3 (29.7x42.0 cm), A4 (21.0x29.7 cm), B1 (72.8x102.8 cm), B2 (51.4x72.8 cm), B3, B4, 17", 24", 44", 36"
Print Margins Sheet Media
Mode 1: 3 mm (top), 3 mm (right), 14 mm (bottom), 3 mm (left)
Compatible Paper Thickness
0,08 mm - 1,5 mm
Borderless printing on
10 inches, 11.81 inches, 12.95 inches, 15.98 inches, 17.01 inches, 20.28 inches, 23.39 inches, 24.02 inches, 28.66 inches, 33.11 inches, 35.98 inches, 40.55 inches, 44.02 inches
General
Power consumption
64 Watt, 3 Watt (standby), 0,5 Watt (Power off)
Supply Voltage
AC 100 V - 240 V, 50 Hz - 60 Hz
Product dimensions
1.608 x 813 x 1.128 mm (Width x Depth x Height)
Sound Power
Operation: 6,8 B (A)
Noise Level
Operation (Roll): 50 dB (A)
What's in the box
Driver and utilities (CD), Individual Ink Cartridges, Maintenance box, Power cable, Printer Stand with stacking print basket, Setup guide, SureColor T-Series Printer, User manual (CD)
Optional extras
Wide Format Scanner, Hard Drive, Adobe Postscript 3 enablement unit (includes HDD), Attachment for Auto Take up reel unit, Document carrier sheet A0, Roll Adapter, Cover Plus warranty extensions
Other Features
Compatible Operating Systems
Linux, Mac OS 10.5.8 or later, Windows 10, Windows 7, Windows 7 x64, Windows 8 (32/64 bit), Windows 8.1, Windows 8.1 x64 Edition, Windows Server 2003 (32/64bit), Windows Server 2008 (32/64bit), Windows Server 2008 R2, Windows Server 2012 (64bit), Windows Server 2012 R2, Windows Vista (32/64 bit), Windows XP, Windows XP x64
Emulations
HP-GL2, RTL, Adobe® Postscript 3® (optional), ESC/P-R
Features
Direct scan-to-print without PC
Scanner not included with delivery
Yes
Interfaces
Hi-Speed USB - compatible with USB 2.0 specification, Ethernet Interface (1000 Base-T/ 100-Base TX/ 10-Base-T)
Optional Software & Solutions
Epson Print Automate, Dinax Mirage
Security
TLS, SSL, IEE 802, SNMP, IPSec, IPv6
Media Handling
Auto cutter, Auto take up reel, Borderless Print, Borderless Print (up to 10 x 15cm), Fine Art, Roll Paper
Other
Warranty
12 months On-site service
LCD and Memory Cards
Panel
Type: Color, Diagonal: 6,8 cm
Scan
Scanner type
Contact image sensor (CIS)
Media width
38" (153mm to 965.2mm)
Optional scanner
36" Scanner - Tx200 series
Scan width
36" (153mm to 914.4mm)
Maximum scan length
30,5 m
Accessories
Consumables
Epson inks have been developed to work flawlessly with Epson printers to deliver crisp, smudge-proof text that will last for generations. If you're looking for more information on the page yield and how to make the most of our inks,
