Smooth workflows

Use the Full Auto Mode feature to automatically apply the best settings for each scanned image. Seamlessly connect to the cloud with CaptureOnTouch software and create searchable PDF documents using the Optical Character Recognition (OCR) feature.

Energy-efficient technology

Thanks to energy-saving technologies, the DR-F120 allows to keep costs low. The scanner has a high energy-efficiency of less than 20W in operation.

• Type
  Desktop Type Flatbed Scanner with ADF
• Scanning Sensor Unit
  CMOS CIS 1Line Sensor
• Optical Resolution
  600dpi ADF / 1200dpi Flatbed
• Light Source
  RGB LED
• Scanning Side
  Front / Back / Duplex
• Interface
  High Speed USB 2.0
• Dimensions (WxDxH)
  Tray Closed : 469 (W) x 335 (D) x 120 (H) mm
  Tray Opened: 495 (W) x 335 (D) x 201 (H) mm
• Weight
  Approx. 4.6kg
• Power Requirements
  AC220 - 240V (50/60Hz)
• Power Consumption
  Scanning 19.9W or less,
  Sleep Mode 2.3W or less,
  Power Turned Off 0.2W or less
• Operating Environment
  10 - 32.5 °C (50 - 90.5 °F),
  Humidity: 20 - 80% RH
• Environmental Compliance
  RoHS

Scanning Specifications

• Black and White
  ADF: 20ppm / 36ipm
• Colour
  ADF: 10ppm / 18ipm
• Output Resolution
  150 x 150dpi, 200 x 200dpi,
  240 x 240dpi, 300 x 300dpi,
  400 x 400dpi, 600 x 600dpi,
  1200 x 1200dpi, 2400 x 2400dpi
• Output Mode
  Black & White, Error Diffusion, Advanced Text
  Enhancement, Advanced Text Enhancement II, 8-bit
  Greyscale (256-Level), 24-bit Colour
• Suggested Daily Duty Cycle
  From 500 to 1,500 scans/day

Document Specifications

• Width
  ADF: 51 - 216mm
  Flatbed: up to 216mm
• Length
  ADF: 89 - 356mm
  Flatbed: up to 356mm
• Thickness
  ADF: 35 - 128g/m² (0.05 - 0.15mm)
• Long Document Mode
  up to 1000mm
• Business Card Scanning
  Width: 51mm Length: 89mm Thickness 128 - 209g/m²
• Paper Separation
  Retard Roller Method
• Feeder Capacity
  50 sheets (80g/m²)

Special Features

• Special Features
  Automatic Page Size Detection, Deskew, Auto Colour Detection, Text Enhancement, Skip Blank Page, Text Orientation, MultiStream, Preset Gamma Curve, Prescan, Edge Emphasis, Colour Dropout (RGB), Colour Enhancement (RGB), Moire Reduction, Character Emphasis, Prevent Bleed Through/ Remove Background, Remove Shadow, Border Removal, Erase Dot, Erase Notch, Punch Hole Removal, Apply corrections for photos, Double Feed Detection (By Length), Automatic Feeder/Flatbed detection, Rapid Recovery System

Bundled Software

• Windows
  ISIS /TWAIN Driver
  CaptureOnTouch

Other Options

• Consumables
  Exchange Roller Kit
